Name: Schneider LC1DT60AM7 TeSys D Contactor, 4P (4 NO) AC-3 40A 220 V AC Coil
SKU: 1421
Availability: InStock

Schneider LC1DT60AM7 TeSys D Contactor, 4P (4 NO) AC-3 40A 220 V AC Coil

~~₨ 45,000~~
₨ 33,750

Range: TeSys Deca
Component Type: Contactor
Device short name: LC1D
Poles description: 4 Pole
Net weight: 1.09 kg
Pole contact composition: 4 NO
Auxiliary contact composition: 1 NO + 1 NC
Operational Current Ampere: 40A
Thermal Current Ampere: 60A
Capacity: 22 / 30 KW (HP)

Ampere Rating

No of Pole

Clear

Request a Quote

SKU: N/A Categories: Contactors, Magnetic Contactors and Overload Relays

Additional information

Ampere Rating	60A
No of Pole	4 Pole

Product Specifications

Range of product	tesys deca
component type	contactor
device short name	lc1d
contactor application	resistive load
poles description	4p
net weight	1.09 kg
thermal current ampere	60a
capacity	22 / 30 kw (hp)
rated operational voltage [ue]	power circuit; <= 690 v ac 25…400 hz / power circuit; <= 300 v dc
rated operational current [ie]	60
control circuit voltage [uc]	220 v ac 50/60 hz
compatibility code	lc1d
pole contact composition	4 no
contact compatibility	m6
protective cover	with
conventional free air thermal current [ith]	60 a (at 60 °c) for power circuit / 10 a (at 60 °c) for signalling circuit
rated breaking capacity	800 a at 440 v for power circuit conforming to iec 60947
average impedance	1.6 mohm – ith 60 a 50 hz for power circuit
overvoltage category	iii
pollution degree	3
mechanical durability	6 mcycles
control circuit type	ac at 50/60 hz
operating time	4…19 ms opening / 12…26 ms closing
maximum operating rate	3600 cyc/h 60 °c
auxiliary contact composition	1 no + 1 nc
signalling circuit frequency	25…400 hz
minimum switching voltage	17 v for signalling circuit
minimum switching current	5 ma for signalling circuit
insulation resistance	> 10 mohm for signalling circuit
mounting support	plate / rail
operating altitude	0…3000 m
fire resistance	850 °c conforming to iec 60695-2-1
flame retardance	v1 conforming to ul 94

Product Details

TeSys D contactor, 4 poles (4NO), for non-inductive load applications up to 60A/440V AC-1. It provides a 220V 50/60Hz AC coil, 1NO+1NC built-in auxiliary contacts (NC mirror certified), power connections by EverLink BTR screw terminals and control by screw clamp terminals. For operating rates until 3600 cycles/hour and environments until 60°C, it procures high reliability and durability. Compact (70mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).
