Schneider NSX250H 3 Pole Molded Case Circuit Breaker, 70 kA
₨ 120,000
₨ 90,000
- Range: ComPacT new generation
- Product name: ComPacT NSX new generation
- Product or component type: Circuit breaker
- Device application: Distribution
- Poles description: 3P
- Protected poles description: 3D
- [In) rated current: 200 A at 40 oc
- [Uel rated operational voltage: 690 V AC 50/60 Hz
- Network type: AC
- Network frequency: 50/60 Hz
Additional information
| Ampere Rating | 200A, 250A |
|---|---|
| No of Pole | 3 Pole |
Product Specifications
|
Range
|
compact new generation
|
|
product name
|
compact nsx new generation
|
|
device short name
|
nsx250h
|
|
product or component type
|
circuit breaker
|
|
device application
|
distribution
|
|
poles description
|
3p
|
|
protected poles description
|
3d
|
|
[in) rated current
|
200 a at 40 oc
|
|
[uel rated operational voltage
|
690 v ac 50/60 hz
|
|
network type
|
ac
|
|
network frequency
|
50/60 hz
|
|
suitability for isolation
|
yes conforming to en/iec 60947-2
|
|
utilisation category
|
category a
|
|
[icu] rated ultimate short-circuit breaking capacity
|
70 ka
|
|
performance level
|
h 70 ka415vac
|
|
trip unit name
|
tm-d
|
|
trip unit technology
|
thermal-magnetic
|
|
trip unit protection functions
|
li
|
|
control type
|
toggle
|
|
circuit breaker mounting mode
|
fixed
|
|
[ui] rated insulation voltage
|
800 v ac 50/60 hz
|
|
[uimpj rated impulse withstand voltage
|
8 kv
|
|
mechanical durability
|
20000 cycles
|
|
electrical durability
|
20000 cycles at 440 v in/2 / 10000 cycles at 440 v in / 10000 cycles at 690 v in/2 / 5000 cycles at 690 v in
|
|
weight
|
2.4 kg
|
|
standards
|
en/iec 60947
|
|
product certifications
|
ccc / marine / eac
|
|
pollution degree
|
3 conforming to iec 60664-1
|
|
ip degree of protection
|
ip40 conforming to iec 60529
|
|
ik degree of protection
|
ik07 conforming to iec 62262
|
|
ambient air temperature for operation
|
-25…70 °c
|
|
ambient air temperature for storage
|
-50…85 °c
|
|
relative humidity
|
0…95 %
|
|
operating altitude
|
0…2000 m without derating / 2000 m…5000 m with derating
|
Product Details
This ComPacT NSX250H is a complete 3P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 70kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 200A, 250A rating thermal-magnetic trip unit (TMD). TMD trip unit provides an adjustable thermal overload protection and a fixed magnetic protection. This 3 poles version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. ComPacT NSX250H is part of Schneider Electric EcoStruxure Power architecture.
Related products
-
- Circuit Breakers, Molded Case Circuit Breakers
Schneider CVS160F 3 Pole Molded Case Circuit Breaker, 36 kA
-
₨ 41,000
₨ 30,750 - Select options This product has multiple variants. The options may be chosen on the product page
-
- Circuit Breakers, Molded Case Circuit Breakers
Schneider NS800H 3 Pole 800A Molded Case Circuit Breaker, 70 kA
-
