Schneider LC1G800 TeSys F Contactor, 4P (3 NO) AC-3 800 A 220 V AC Coil
₨ 1,090,000
₨ 817,500
- Rated for 800A (AC-3) for heavy-duty use.
- Ensures efficient motor switching.
- 3P (3 NO) contacts for strong connectivity.
- Operates on 220V AC coil voltage.
- Built for long-lasting durability.
- Meets IEC, UL, and other safety standards.
- Easy installation with plate mounting.
- Compact design for space-saving panel integration
Additional information
| Ampere Rating | 800A |
|---|---|
| No of Pole | 3 Pole |
Product Specifications
|
Range
|
tesys
|
|
range of product
|
tesys giga
|
|
product or component type
|
contactor
|
|
device short name
|
lc1g
|
|
contactor application
|
power switching
|
|
utilisation category
|
ac-3 ac-3e ac-1 ac-5a ac-5b ac-6a ac-6b dc-1 dc-3 dc-5
|
|
poles description
|
4p
|
|
[ue] rated operational voltage
|
<= 1000 v ac 50/60 hz <= 460 v dc
|
|
[ie] rated operational current
|
800 a (at <60 °c) at <= 440 v ac-3
|
|
1050 a (at <40 °c) at <= 1000 v ac-1
|
[uc] control circuit voltage 100…250 v ac 50/60 hz 100…250 v dc
|
|
control circuit voltage limits
|
operational
|
|
[uimp] rated impulse withstand voltage
|
8 kv
|
|
overvoltage category
|
iii
|
|
[ith] conventional free air thermal current
|
1050 a (at 40 °c)
|
|
rated breaking capacity
|
5870 a at 440 v
|
|
[icw] rated short-time withstand current
|
5.5 ka – 10 s 4.6 ka – 30 s 3.6 ka – 1 min 2.6 ka – 3 min 1.7 ka – 10 min
|
|
associated fuse rating
|
800 a am at <= 440 v for motor 630 a am at <= 690 v for motor 1250 a gg at <= 690 v
|
|
average impedance
|
0.000065 ohm
|
|
[ui] rated insulation voltage
|
1000 v
|
|
power dissipation per pole
|
70 w ac-1 – ith 1050 a 42 w ac-3 – ith 800 a
|
|
compatibility code
|
lc1g
|
|
pole contact composition
|
4 no
|
|
auxiliary contact composition
|
1 no + 1 nc
|
|
irms rated making capacity
|
7640 a at 440 v
|
|
coil technology
|
built-in bidirectional peak limiting safety reliability level
|
|
mechanical durability
|
5 mcycles
|
|
inrush power in va (50/60 hz, ac) 800 va
|
|
|
inrush power in w (dc)
|
680 w
|
|
hold-in power consumption in va (50/60 hz, ac)
|
15.0 va
|
|
hold-in power consumption in w (dc)
|
9.5 w
|
|
operating time
|
40…70 ms closing 15…50 ms opening
|
|
maximum operating rate
|
600 cyc/h ac-3 600 cyc/h ac-3e 300 cyc/h ac-1
|
|
connections – terminals
|
power circuit
|
|
ightening torque
|
58 n.m
|
|
height
|
284 mm
|
|
width
|
281 mm
|
|
depth; 266 mm
|
|
|
net weight
|
18 kg
|
Product Details
The Schneider LC1G800 TeSys F Contactor is a high-performance solution for power switching and motor control applications. Designed for reliability, it supports AC-3 utilization up to 800A and operates on a 220V AC coil, making it ideal for industrial settings
