Schneider IMN UVT 220v OC Contact Ac For MCB
₨ 20,000 ₨ 15,000
- FOR IC60N SERIES
- Compatible with various Schneider Acti 9 MCB models.
- IP20 degree of protection ensures durability and safety.
- Clip-on mounting on DIN rails for easy installation.
- Clamp terminals for secure connections.
- Operates at 220-240V AC 50/60 Hz control circuit voltage.
- Meets EN/IEC 60947-5-1 standards for reliability.
Product Specifications
|
Color
|
white
|
|
for
|
ic60n series
|
|
ambient air temperature for operation
|
-25…50 °c
|
|
ambient air temperature for storage
|
-40…85 °c
|
|
ip degree of protection
|
ip20 conforming to en/iec 60947-5-1
|
|
mounting mode
|
clip-on
|
|
mounting support
|
din rail
|
|
standards
|
en/iec 60947-5-1
|
|
product or component type
|
undervoltage release
|
|
control type
|
standard
|
|
tightening torque
|
1 n.m
|
|
tropicalisation
|
2 conforming to en/iec 60947-5-1
|
|
type
|
oc contact
|
|
width
|
18 mm
|
|
control circuit voltage [uc]
|
220…240 v ac 50/60 hz
|
Product Details
Introducing the Schneider IMN UVT 220V AC Undervoltage Release for MCB. This white-colored release is designed for compatibility with various Schneider Acti 9 MCB models, ensuring reliable performance. With an IP20 degree of protection, it offers durability and safety in operation. Easy clip-on mounting on DIN rails makes installation hassle-free. The release features clamp terminals for secure connections and operates at a control circuit voltage of 220-240V AC 50/60 Hz. Ideal for applications requiring undervoltage protection, this release meets EN/IEC 60947-5-1 standards and operates within an ambient air temperature range of -25°C to +50°C during operation and -40°C to +85°C during storage.
