Name: Schneider Acti9 Auxiliary fault contact iSD
SKU: :A9A26927
Availability: InStock

Schneider Acti9 Auxiliary fault contact iSD

~~₨ 15,000~~ ₨ 11,250

For IC60N Series
Operating frequency: 50Hz or 60Hz.
Compact 9mm width, white color.
Lightweight design weighing 33g.
Degree of protection: IP20 at terminals, IP40 in enclosure.
Operating temperature range: -35°C to +70°C.
Storage temperature range: -40°C to +85°C.
Compliance with EN/IEC 60947-5-1 standard.

SKU: :A9A26927 Categories: Accessories, Circuit Breakers

Product Specifications

Range of product	acti9
for	ic60n series
product or component type	fault contact
device short name	isd
signal contacts composition	1 c/o
rated insulation voltage [ui]	500 v
rated impulse withstand voltage [uimp]	4 kv
local signalling	mechanical indicator
mounting mode	clip-on
mounting support	din rail
height	86 mm
width	9 mm
depth	73 mm
net weight	33 g
colour	white

Product Details

This Acti9 iSD electric auxiliary is a remote fault indicator contact. It is dedicated to iC60, iC40, iCV40, iID, iID40, iDPN Vigi, iSW-NA, iC60 & iID products. It comes with 1 changeover contact indicating the position of the associated device. It indicates the position of the associated device in the event of an electrical fault or action on the tripping auxiliary. There is a mechanical state indicator and a test function button on the front face. The Ue-rated operational voltage is 24VAC to 415VAC or 24VDC to 130VDC. The operating frequency is 50Hz or 60Hz. The Ie rated operational current is 6A under 24VDC, 2A under 48VDC, 1.5A under 60VDC, 1A under 130VDC. The Ie-rated operational current is 6A under 24VAC to 240VAC, 3A under 415VAC. The width in 9mm pitches is 1. The product color is white (RAL9003). The dimensions are (W) 9mm x (H) 86mm x (D) 73mm. The product weight is 33g. The degree of protection is IP20 at terminals and IP40 in the enclosure. The operating temperature is -35°C to +70°C. The storage temperature is -40°C to +85°C. This product complies with EN/IEC 60947-5-1 standard.
