Schneider Variable Speed Drive Altivar 610 Series, 18.5kW, 25hp
- High-performance motor control for 18.5kW (25HP) applications
- Optimized for HVAC, pumping, and fluid management systems
- Built-in EMC filter and integrated protections for safety
- User-friendly graphical interface with easy navigation
- Energy-saving modes reduce operational costs
- Advanced diagnostics and communication capabilities
- Compatible with Modbus, BACnet, and other fieldbuses
- Robust design for harsh environments
Product Specifications
|
Power rating
|
18.5kw / 25hp voltage range
|
|
interface
|
graphical keypad with lcd
|
|
communication protocols
|
modbus, canopen, bacnet, ethernet (via optional cards)
|
|
protection features
|
overload, short-circuit, overvoltage, and thermal protection
|
|
cooling method
|
forced air
|
|
certifications
|
ce, ul, csa, rohs
|
|
applications
|
hvac, water treatment, building management, and industrial processes
|
Product Details
This Easy Altivar 610 drive is a frequency inverter for three-phase asynchronous motors. It works at a rated supply voltage from 380V to 415V AC. It is suitable for motors with power rating up to 15kW / 20hp for applications requiring slight overload (up to 120%). It is suitable for motors with power rating up to 11kW / 15hp for applications requiring significant overload (up to 150%). It offers a plug & play solution, whereby parameters are preset in the factory to the desired configuration, to help save process control and operating time. It has integrated radio interference input filters in accordance with the EMC standard for variable speed electrical power drive “products” IEC/EN 61800-3, edition 2, category C3 in environment 1 or 2. It weighs 7.2kg and its dimensions are, 171mm wide, 360mm high, 233mm deep. this drive has been specially designed for standard applications in the market segments water and wastewater and oil and gas and in the domains process and machine management and building management.
