Name: Schneider EZC250F 3 Pole Molded Case Circuit Breaker, 18 kA
SKU: 818
Availability: InStock

Schneider EZC250F 3 Pole Molded Case Circuit Breaker, 18 kA

~~₨ 35,000 – ₨ 39,000~~
₨ 26,250 – ₨ 29,250

Range Of product: EasyPact
Product or component type: Circuit breaker
circuit breaker name: Easypact EZC250F
Device application: Distribution
Poles description: 3P
Protected poles description: 3t
Network type: DC/AC
Network frequency: 50/60 Hz

Ampere Rating

No of Pole

Clear

Request a Quote

SKU: N/A Categories: Circuit Breakers, Molded Case Circuit Breakers

Additional information

Ampere Rating	125A, 150A, 200A, 225A, 250A
No of Pole	3 Pole

Product Specifications

Range of product	easypact
product or component type	circuit breaker
circuit breaker name	easypact ezc250f
device application	distribution
poles description	3p
protected poles description	3t
network type	dc/ac
network frequency	50/60 hz
[in] rated current	125 a at 40 oc
[ui] rated insulation voltage	690 v ac 50/60 hz conforming to iec 60947-2
[uimpj rated impulse with stand voltage	6 kv conforming to iec 60947-2
[uel rated operational voltage	550 v ac 50/60 hz conforming to iec 60947-2 / 250 v dc conforming to iec 60947-2
breaking capacity code	f
breaking capacity	18 ka icu at 380 v ac 50/60 hz conforming to iec 60947-2
suitability for isolation	yes conforming to iec 60947-2
utilisation category	category a
trip unit name	tm-d
trip unit technology	thermal-magnetic
trip unit rating	125 a at 50 oc
protection type	overload protection / short-circuit protection
pollution degree	3 conforming to iec 60664-1 / 3 conforming to iec 947-1
control type	toggle
mounting mode	fixed
mounting support	backplate
upside connection	front
downside connection	front
mechanical durability	10000 cycles
standards	en/iec 60947-2 / gbi’t 14048.2 / en/iec 60947-1
ip degree of protection	ip20 conforming to iec 60529
1k degree of protection	ik07 conforming to iec 62262
ambient air temperature for operation	-25…70 c
ambient air temperature for storage	-35…85 c

Product Details

EasyPact EZC250F is a 3 poles fixed circuit breaker designed for the protection of low voltage electrical installations. It is used for standard applications in industries and buildings, offering good performance at a competitive price The breaking capacity (Icu) is 18kA rms at 415VAC 50/60Hz. The operational voltage is 550VAC 50/60Hz or 250VDC. The rating of the thermal-magnetic trip unit is 125A, 150A, 200A, 225A, 250A. The trip unit provides fixed overload and instantaneous protections. This 3-pole version (105mm x 165mm x 60mm) comes with a variety of optional functions and accessories. Easypact EZC250F is compliant with international standards (IEC 60947, UL 508) and marine certifications.
